Deurtelefoon Accessoires
Helios/2N 2N Bluetooth & RFID lezer (125 kHz, secured 13,56MHz, NFC)
TOUCH KEYPAD & RFID READER 125KHZ, SECURED 13.56MHZ, NFC
Module for 2N® IP Verso and 2N® LTE Verso that combines a capacitive touch keypad with secured RFID reader. Thanks to the multi-frequency RFID reader the module can read a wide range of RFID cards from unsecured 125kHz cards to smart and even secured 13.56MHz cards. Furthermore, the keypad is used for PIN verification and for additional layer of security.
*Multi-frequency RFID card reader
*Reads secured RFID cards
*Keypad used for access control and callings
Helios/2N 2N Opbouw installatie afdekframe voor 1 module for 1 module silver
FRAME FOR INSTALLATION ON THE SURFACE – 1 MODULE
Frame for installation on the surface, 1 module. No other accessories are needed for surface installation of the intercom/access control reader. When installing on a glass or uneven surface, we recommend you use a backplate.
*107 (W) x 130 (H) x 28 (D) mm
Helios/2N 2N Opbouw installatie afdekframe voor 3 modules frame for 3 modules - silver
FRAME FOR INSTALLATION ON THE SURFACE – 3 MODULES
Frame for installation on the surface, 3 modules. No other accessories are needed for surface installation of the intercom. When installing on a glass or uneven surface, we recommend you use a backplate.
*Suitable for These Products: 2N® IP VERSO and 2N® LTE VERSO
*107 (W) x 339 (H) x 28 (D) mm
Helios/2N Verso Microphone Set 2N
2N® IP Verso microphone set
Helios/2N 2N IP Verso keypad module
KEYPAD
The numeric keypad module helps you dial users via their phonebook positions or phone numbers, control the lock and use other code-accessible functions. The keypad digits and symbols are backlit. Available also in black (9155031B).
*Suitable for These Products: 2N® IP VERSO, 2N® LTE VERSO, 2N Access Unit 2.0
Helios/2N 2N IP Verso main unit met camera (zwart) black - IP54
2N® IP VERSO
The 2N® IP Verso security intercom is configurable to your needs thanks to its modularity. It provides reliable access control and allows you to easily interface with other systems, achieving even higher site security. Available also in black, with a fingerprint reader, Bluetooth module, or touch display.
*Progressive mobile access
*Touchscreen
*Camera with night vision
Helios/2N Helios IP Style surface installation chassis
SURFACE MOUNT BOX
Use the mounting backplate to install the 2N® IP Style intercom on the surface of a wall. The box includes a unique tilt-out mechanism which gives you plenty of room to work with cabling.
*Intercom dimensions with the surface-mounting installation box: 170 (W) x 355 (H) x 40 (D) mm
Helios/2N 2N Inbouw installatie frame voor 1 module (zwart) black (9155014 nodig)
Helios/2N 2N Bluetooth & RFID lezer (125 kHz, secured 13,56MHz, NFC)
BLUETOOTH & RFID READER 125KHZ, SECURED 13.56MHZ, NFC
The reader for 2N® IP Verso and 2N® LTE Verso intercom that combines the RFID technology with a modern approach to access control based on the Bluetooth mobile credentials. This compact module uses multi-frequency RFID reader and reads also secured RFID cards. It also offers a possibility for authentication using a smartphone with installed 2N® Mobile Key app. All you have to do is tap the button in the application or in the Touch mode, you can even leave your phone in your pocket and open the door by simply touching the reader.
*Open doors using a smartphone
*Mobile credentials for free
*Reads secured RFID cards
(€ 690,26 incl.btw)
Helios/2N Access Unit 2.0 RFID - 125kHz, secured 13.56MHz NFC*
Helios/2N 2N IP Verso keypad module (zwart)
Helios/2N Helios IP Style flush box
FLUSH-MOUNT BOX
Use this mounting box to install the 2N® IP Style into a wall. The flush-mounting box has a special elevating function. It helps you align the intercom with a wall’s surface so that only the correct part of the intercom shows. In other words, a hole in the wall which is too deep won’t ruin the whole installation. The box has a unique tilt-out mechanism which gives you plenty of room to work with cabling.
*Box dimensions: 170 (W) x 355 (H) x 46 (D) mm
*Intercom dimensions above the surface: 170 (W) x 355 (H) x 22 (D) mm
Helios/2N Helios IP Verso - RFID Card Reader 125kHz
RFID card reader 13,56 MHz 125 kHz
Deze 2N IP Verso uitbreidingsmodule biedt een RFID lezer op 125 kHz. Voor het herkennen van RFID kaarten en tags voor bijvoorbeeld het openen van de deur. Te plaatsen in 9155011© / 9155014 / 9155015 / 9155016 / 9155021 / 9155022 en 9155023.
Helios/2N 2N Opbouw installatie afdekframe frame for 3 modules - black
FRAME FOR INSTALLATION ON THE SURFACE – 3 MODULES
Frame for installation on the surface, 3 modules. No other accessories are needed for surface installation of the intercom. When installing on a glass or uneven surface, we recommend you use a backplate.
*Suitable for These Products: 2N® IP VERSO and 2N® LTE VERSO
*107 (W) x 339 (H) x 28 (D) mm
Helios/2N Bluetooth & RFID reader (125 kHz, 13,56MHz, NFC) (125kHz, 13,56MHz, NFC)
BLUETOOTH & RFID READER 125KHZ, 13.56MHZ, NFC
The Bluetooth & RFID module for 2N® IP Verso and 2N® LTE Verso combines the currently leading RFID technology with a modern approach to access control based on the Bluetooth technology. Thanks to the multi-frequency RFID reader it reads both, unsecured 125kHz cards and smart 13.56MHz cards. Doors can also be opened with the aid of a smartphone with the installed 2N® Mobile Key application! By tapping the button in the app or by simply touching the reader.
*Reads majority of access cards on the market
*Open doors using a smartphone
*Mobile credentials for free
Helios/2N 2N® IP Phone D7A
Helios/2N 2N IP Verso intercom (zwart)
Helios/2N Access Unit 2.0 RFID - 125kHz, 13.56MHz, NFC* NFC*
Helios/2N 2N IP Verso - 13.56MHz secured card RFID reader NFR ready
SECURED RFID CARD READER 13.56 MHZ NFC
Compatible with firmware 2.13 and higher. The card reader module provides you with access control via contactless cards or keyfobs. The module supports the following 13.56 MHz cards or other carriers (optionally card serial number or PAC ID is read).
*ISO/IEC 14443A Mifare Classic 1k & 4k, DESFire EV1, Mini, Plus S&X, Ultralight, Ultralight C
*ISO/IEC 14443B CEPAS, HID iCLASS
*JIS X 6319 Felica
*ISO/IEC 18092 SmartPhone with NFC/HCE support, since Android version 6
https://www.2n.com/en_GB/documents/22902/2210357/ip_verso_rfid_reader_13_56mhz_datasheet_a4_en.pdf/38732177-08d2-48ea-8994-e85acea4e0f2
Helios/2N Lift1 Cabin unit - wired
